[Pw_forum] how to get the Eigendisplacements by ph.x

tanycimr at gmail.com tanycimr at gmail.com
Tue Apr 12 02:37:25 CEST 2011


Thanks  . The advice give me a lot of help

Tanyci
Nankai university , tianjin
China




-------Original Message-------

From: Eyvaz Isaev
Date: 2011-4-11 22:40:44
To: PWSCF Forum
Subject: Re: [Pw_forum] how to get the Eigendisplacements by ph.x

Well, I was somewhat wrong. If you need eigendisplacements for q-points
(from nq1*nq2*nq3 mesh in ph.in file) then just have look at  *.dynN files.
They contain both frequencies and eigendisplacements for these q-ponts.


Eyvaz.



From: Eyvaz Isaev <eyvaz_isaev at yahoo.com>
To: PWSCF Forum <pw_forum at pwscf.org>
Sent: Mon, April 11, 2011 3:58:58 PM
Subject: Re: [Pw_forum] how to get the Eigendisplacements by ph.x


Hi,

>Use dynmat.x after ph.x.
>In the source file you will find the keywords explained PH/dynmat.f90

Yes, it is true, if  one interested in the Gamma-point only.
Otherwise, one has to use matdyn.x for an arbitrary q-point. Sure,
Interatomic Force Constants
Matrix is required.

Bests,
Eyvaz..

-------------------------------------------------------------------
Prof. Eyvaz Isaev,
Department of Physics, Chemistry, and Biology (IFM), Linkoping University,
Sweden
Theoretical Physics Department, Moscow State Institute of Steel & Alloys,
Russia,
isaev at ifm.liu.se, eyvaz_isaev at yahoo.com






From: Eduardo Ariel Menendez Proupin <eariel99 at gmail.com>
To: pw_forum at pwscf.org
Sent: Mon, April 11, 2011 2:15:30 PM
Subject: [Pw_forum] how to get the Eigendisplacements by ph.x


> want to know how to get the Eigendisplacements  by ph.x . what i found in
the dyn_G file is just "Diagonalizing the dynamical matrix"



Use dynmat.x after ph.x.


In the source file you will find the keywords explained
PH/dynmat.f90


Good luck,
--





Eduardo Menendez
Departamento de Fisica
Facultad de Ciencias
Universidad de Chile
Phone: (56)(2)9787439
URL: http://fisica.ciencias.uchile.cl/%7Eemenendez
